Feature:
Output power 4/5W
Receive FM Radio
128 Signal-duplex channels, three-color LCD backlight display
Voice annunciation (Chinese or English)
CTCSS+DCS encode and decode+DTMF encode/decode
Multi-Scan mode: VFO scan+DCS scan
VOX function (3 levels), voice scramble & compander, wide/narrow band
DTMF ANI function
Squelch Tail Elimination function
Emergency lighting function
|
General |
|
Frequency Range |
VHF: 136-174MHz UHF:350-390MHz
UHF: 400-470MHz UHF:450-520MHz |
|
Channel Capacity |
128 channels |
|
Channel Spacing |
25KHz(Wide Band) 20KHz(Middle Band) 12.5KHz(Narrow band) |
|
Phase-locked Step |
5KHz,6.25KHz |
|
Operating Voltage |
7.4V DC ±15% |
|
Battery Life |
More than 14 Hours (1350mAh), by 5-5-90 working cycle |
|
Frequency Stability |
±2.5ppm |
|
Operating Temperature |
-20°C +55°C |
|
Size |
260×57×37mm (with battery, antenna) |
|
Weight |
210 g (with battery, antenna) |
|
Receiver (ETSI EN 300 086 standard testing ) |
|
|
Wide band |
Narrow band |
|
Sensitivity (12dB Sinad) |
≤0.25μV |
≤0.35μV |
|
Adjacent Channel
Selectivity |
≥70dB |
≥60dB |
|
Intermodulation |
≥65dB |
≥60dB |
|
Spurious Rejection |
≥70dB |
≥70dB |
|
Audio Response |
+1~-3dB(0.3~3KHz) |
+1~-3dB(0.3~2.55KHz) |
|
Hum & Noise |
≥45dB |
≥40dB |
|
Audio distortion |
≤5% |
|
Audio power output |
500mW / 10% |
|
Transmitter (ETSI EN 300 086 standard testing ) |
|
|
Wide band |
Narrow band |
|
Power Output |
4W/2W/0.5W |
|
Modulation |
16KΦF3E |
11KΦF3E |
|
Adjacent Channel
Power |
≥70dB |
≥60dB |
|
Hum & Noise |
≥40dB |
≥36dB |
|
Spurious Emission |
≥-36dB |
≥-36dB |
|
Audio Response |
+1~-3dB(0.3~3KHz) |
+1~-3dB(0.3~2.25KHz) |
|
Audio Distortion |
≤5% |
Each Sets Standard Accessories:
1 x AT-288G Radio
1 x Antenna (VHF or UHF)
1 x Battery
1 x Charger
1 x AC Adaptor
1 x Belt Clip
1 x ENG Instruction Manual
|
