Anytone AT-5888UV-III Tri-Band 2 Meter
220 MHz 70cm Mobile Radio FM Transceiver
AT-5888UV III TRI-BAND FM TRANSCEIVER
Brand:
Anytone
Model:
5888UV III
Series
Model: 5888 TRI-BAND, 5888III
Model
Different All the same except for the model name.
Communication Type Voice / Tone only
Modulation FM
Power
Supply DC 13.8V by DC source
Tri-band: 2m (144Mhz) / 1.25cm (220Mhz) / 70cm (440Mhz)
MIC Connector Diagram (in the front view of connector)
AT-5888UVIII Tri-Band Mobile Radio FM
Transceiver
Frequency Range:
RX: VHF 1: 136-174MHZ, UHF1: 220-260MHZ,
UHF2: 400-512MHZ
TX: VHF 1: 144-148MHZ, UHF1: 222-225MHZ,
UHF2: 420-450MHZ
Function:
Working Mode: Full duplex on UU, UV, VV, UV
or VU as repeater mode
Dual Receive: Consist with A & B band
Power: VHF1: 55W/25W/10W/5W UHF1:
25W/10W/5W, UHF3: 45W/25W/10W/5W
758 memory channels
CTCSS+DCS+DTMF+2Tone/5Tone encode and decode
Bandwidth: 12.5KHZ/25KHZ
Compander
Scramble function (9 groups fixed+2groups be
defined by user)
Channel step: 2.5/6.25/10/12.5/15/20/25/50KHZ
ANI function (DTMF/ANI, 5-Tone/ANI) PTT ID.
DTMF Microphone
|
